Short-length Multi-walled carbon nanotubes (MWCNT)：
Product Code : TNSM1, TNSMH1, TNSMC1
Technical Data (pdf)

TNSM1 (Download)

TNSMH1 (Download)

TNSMC1 (Download)

Product Description:
Timestub^TM --Short-length High purity Multi-walled carbon nanotubes---have three kinds of products: TNSM1, TNSMH1 and TNSMC1.TNSM1 is produced by mechanical cutting TNM1, followed by dis-agglomeration treatment. TNSMH1 and TNSMC1 are the TNSM1 hydroxyl and carboxyl functionalized products, respectively. TNSMH1 and TNSMC1 are prepared by KMnO₄ oxidation in H₂SO₄ solution at different temperature and different KMnO₄ concentration.

Property	Unit	Short-Length MWCNTs			Method of Measurement
		TNSM1	TNSMH1	TNSMC1
OD	nm	5-15	5-15	5-15	HRTEM,Raman
Purity	wt%	>98	>98	>98	TGA & TEM
Length	microns	0.5-2	0.5-2	0.5-2	TEM
SSA	m2/g	>270	>270	>270	BET
ASH	wt%	<2	<2	<2	TGA
Ig/Id	--	--	--	--	Raman
-OH Content	wt%		5.58		XPS & Titration
-COOH Content	wt%			3.86	XPS & Titration
OD=Outer Diameter           ID=Inner Diameter            SSA=Specific Surface Area
