Ni coated Multi-walled carbon nanotubes (MWCNT):
Product Code : TNNiM2, TNNiM3, TNNiM5, TNNiM7, TNNiM8
Technical Data (pdf)

TNNiM2 (Download )	TNNiM3 (Download )	TNNiM5 (Download)
TNNiM7 (Download)	TNNiM8 (Download )

Product Description:
Timestub^TM ---Ni coated Multi-walled carbon nanotube---have five kinds of products: TNNiM2, TNNiM3, TNNiM5, TNNiM7, TNNiM8 by the outer diameter to divided. They are composite of Ni and Carbon nanotubes, and the carbon nanotubes are coated by Ni. These carbon nanotubes are producted via the catalytic carbon vapor deposition (CCVD) process.

Property	Unit	NiMWCNTs					Method of Measurement
		TNNiM2	TNNiM3	TNNiM5	TNNiM7	TNNiM8
OD	nm	8-15	10-20	20-30	30-50	30-80	HRTEM,Raman
Ni Content	wt%	>60	>60	>60	>60	>60	TGA & TEM
CNTs Content	wt%	>38	>38	>38	>38	>38	TGA & TEM
Length	microns	～50	10-30	10-30	<10	<10	TEM
SSA	m2/g	60	60	70	50	40	BET
ASH	wt%						TGA
Ig/Id	--						Raman
OD=Outer Diameter         ID=Inner Diameter         SSA=Specific Surface Area
